Threat Modeling: The Complete Guide for Security and Compliance Teams

What Is Threat Modeling?

Threat modeling is a structured methodology for identifying and mitigating security threats during the design and architecture phase of system development. Rather than waiting to find vulnerabilities through testing, threat modeling proactively analyses how a system could be attacked and builds defences into the design.

Effective threat modeling answers four key questions: What are we building? What can go wrong? What are we going to do about it? Did we do a good enough job?

Threat Modeling Methodologies

Methodology	Approach	Best For	Complexity
STRIDE	Threat classification (6 categories)	Development teams, component analysis	Low-Medium
PASTA	Risk-centric, 7-stage process	Enterprise risk assessment	High
Attack trees	Tree structure mapping attack paths	Specific threat scenarios	Medium
LINDDUN	Privacy-focused threat categories	Privacy-sensitive applications	Medium
VAST	Visual, agile, scalable threat modeling	Large organisations, DevOps	Medium
Kill chain analysis	Adversary behaviour modelling	Incident response preparation	Medium

STRIDE Threat Categories

Category	Threat	Security Property	Countermeasure
Spoofing	Pretending to be another user or system	Authentication	Strong authentication, MFA, certificates
Tampering	Modifying data, code, or configurations	Integrity	Input validation, checksums, digital signatures
Repudiation	Denying actions were taken	Non-repudiation	Audit logging, digital signatures, timestamps
Information disclosure	Exposing data to unauthorised parties	Confidentiality	Encryption, access controls, data masking
Denial of service	Preventing legitimate access to resources	Availability	Rate limiting, redundancy, auto-scaling
Elevation of privilege	Gaining unauthorised access levels	Authorisation	Least privilege, RBAC, input validation

Threat Modeling Process

Step	Activities	Output
1. Scope	Define system boundaries, assets, and trust levels	System context diagram
2. Decompose	Create data flow diagrams showing components, data flows, trust boundaries	DFD with trust boundaries
3. Identify threats	Apply STRIDE or chosen methodology to each element	Threat list with descriptions
4. Assess risk	Rate each threat by likelihood and impact	Prioritised threat matrix
5. Determine countermeasures	Identify security controls for each threat	Countermeasure mapping
6. Validate	Verify countermeasures are effective and implemented	Validation report
7. Document	Record model, decisions, and residual risks	Threat model document

Data Flow Diagram Elements

Element	Symbol	Examples	Threat Focus
External entity	Rectangle	Users, external APIs, third-party systems	Spoofing, input validation
Process	Circle	Application logic, microservices	All STRIDE categories
Data store	Parallel lines	Databases, file systems, caches	Tampering, information disclosure
Data flow	Arrow	API calls, network connections, file transfers	Tampering, information disclosure
Trust boundary	Dashed line	Network perimeter, service mesh, authentication	All categories (highest risk area)

Risk Assessment Matrix

	Low Impact	Medium Impact	High Impact	Critical Impact
High Likelihood	Medium	High	Critical	Critical
Medium Likelihood	Low	Medium	High	Critical
Low Likelihood	Informational	Low	Medium	High

Common Threat Patterns

Pattern	Description	Where Found	Countermeasure
Broken authentication	Weak or bypassed authentication	Login flows, API endpoints	MFA, session management, token validation
Injection	Untrusted input executed as code	Database queries, OS commands, LDAP	Input validation, parameterised queries
Data exposure	Sensitive data transmitted or stored insecurely	APIs, databases, logs	Encryption, masking, access controls
Privilege escalation	User gains higher access than authorised	Admin functions, role assignments	Least privilege, authorisation checks
Supply chain compromise	Malicious third-party components	Dependencies, integrations, APIs	SCA, SBOM, vendor assessment
Insider threat	Authorised user acts maliciously	All internal systems	Monitoring, separation of duties, access reviews

Compliance Requirements

Framework Mapping

Requirement	ISO 27001	SOC 2	NIS2	DORA
Risk assessment	A.5.7	CC3.2	Art. 21(2)(a)	Art. 8(1)
Threat intelligence	A.5.7	CC3.2	Art. 21(2)(a)	Art. 8(6)
Secure design	A.8.25	CC8.1	Art. 21(2)(e)	Art. 8(1)
Security requirements	A.8.26	CC8.1	Art. 21(2)(e)	Art. 8(1)
Security testing	A.8.29	CC8.1	Art. 21(2)(e)	Art. 8(3)
Change risk assessment	A.8.32	CC8.1	Art. 21(2)(e)	Art. 8(2)

Audit Evidence

Evidence Type	Description	Framework
Threat model documents	Completed threat models for critical systems	All frameworks
Data flow diagrams	Current DFDs showing trust boundaries	ISO 27001, SOC 2
Risk assessment results	Prioritised threat lists with ratings	All frameworks
Countermeasure mapping	Threats mapped to implemented controls	All frameworks
Threat model review records	Evidence of periodic review and updates	ISO 27001, NIS2
Remediation tracking	Tickets showing threat-to-fix workflow	All frameworks
Training records	Developer threat modeling training	ISO 27001, SOC 2

Common Mistakes

Mistake	Risk	Fix
Only modelling at initial design	Drift between model and reality	Update threat models on significant changes
Too abstract, no actionable output	Models provide no security value	Include specific, testable countermeasures
Only security team participates	Missing domain knowledge	Include developers, architects, and product owners
Ignoring trust boundaries	Missing the highest-risk attack surfaces	Map every trust boundary crossing in DFDs
No threat prioritisation	Treating all threats equally	Use risk assessment to focus on critical threats first
Not tracking remediation	Identified threats never addressed	Track countermeasures as security requirements
